The model of the 10N button dedicated dynamometer is GSI315. It is specially designed for the pressing test of key button with "click" action. It is equipped with SPF key test frame, which can be combined into a special key button test machine.
Features:
High precision and high resolution, accuracy level 0.5, minimum reading up to 0.001N.
Comparison function, free setting of upper and lower limit deviation values, red and green indicator lights and buzzer automatic sound and light alarm settings.
Memory function, can store 10 sets of test data, average value calculation function.
Three kinds of unit conversion, can change N, kgf, lbf three kinds of measurement units, and automatic conversion.
The LCD screen can be flipped over. Press and hold the unit key for 3 seconds and then release it to flip the direction of the LCD screen.
Automatic shutdown function, environmental protection, power saving and machine design, shutdown time (1 ~ 60 minutes) can be set freely.
RS-232C serial port output, can be connected to a computer to synchronously display the test force curve and test process record trace, can edit the report format according to actual needs, and can print 10 sets of stored test data and maximum, minimum, average, qualified or Unqualified value judgment.
Technical Parameters:
Product model SH-10F Maximum test load 10N Division value 0.005N Indication error ± 0.5%
